One New ISC Medium Double Aluminum Pulley - RP033A (B1ABIRP033A)
The ISC Medium Double Pulley (RP033A) is a lightweight, high-strength aluminum Eiger-series double pulley designed for rope rescue, climbing, arborist, and rigging applications. It features two sheaves for use in mechanical advantage systems and includes a load-rated becket at the bottom that allows daisy-chaining in block-and-tackle configurations. The pulley is fitted with MOS2 impregnated bushings and tamper-proof rivets, and is individually serial numbered for traceability.
Specifications
- Part Number: RP033A / B1ABIRP033A
- Body Material: High-strength aluminum
- Wheel Material: Aluminum
- Finish: Anodized
- Weight: 284 g (10 oz)
- Height: 110 mm (4-5/16 in.)
- Width: 52 mm (2 in.)
- Depth: 56 mm (2-1/4 in.)
- Maximum Compatible Rope Diameter: 13 mm (1/2 in.)
- Minimum Breaking Strength (MBS): 36 kN (8,093 lbf)
- Working Load Limit (WLL): 809 lbs (367 kg)
- Compliant Standards: CE EN 12278, NFPA 1983
- Individually Serial Numbered
- Made in Wales
Replaces Part Number(s):
RP033A, B1ABIRP033A, A-B1ABIRP033A-AI
New aftermarket replacement part - not remanufactured, not used.
