A-HF6101J Filter, Hydraulic, Cartridge (QTY 1)

One New Aftermarket Replacement Hydraulic Filter (Cartridge) - Fleetguard HF6101 Cross-Reference

This cartridge-style hydraulic filter removes contaminants from hydraulic fluid to protect pumps, valves, and cylinders, maintaining clean fluid and extending the service life of precision hydraulic systems. The A-HF6101J is an aftermarket replacement for the Fleetguard HF6101, a widely used cartridge hydraulic filter in construction, agriculture, and heavy equipment applications.

Specifications

• Style: Cartridge
• Overall Height: 11.5 in (292.1 mm)
• Outer Diameter: 5.1 in (129.54 mm)
• Inner Diameter: 3.35 in (85.09 mm)
• Filtration Rating: 16 micron (Beta=2), 35 micron (Beta=20)

Compatible Equipment

Komatsu Excavators: PC100-1, PC100-2, PC100-3, PC100L-1, PC100L-2, PC100L-3, PC100S-3, PC100SS-3, PC100U-2, PC100U-3, PC100US-3, PC120-1, PC120-2, PC120-3, PC120S-3, PC120SS-3, PC150-3, PC150LC-3, PW100-1, PW150-1

Komatsu Crawler Dozers: D80A-18, D80E-18, D80P-18, D85A-18, D85E-18, D85P-18, D95S-1, D95S-2, D150A-1, D155A-1, D155A-2A

Komatsu Stabilizers: CS360-1 (Crawler), GS360-1 (Wheel)

Also fits equipment using Komatsu OEM filter 175-60-27380 or Fits Caterpillar 8J8850 / 3I1358. Verify fitment against your equipment's filter part number before ordering.

Replaces Part Number(s):

HF6101, HF6102, A-HF6101J

Aftermarket Interchange Numbers

Fleetguard HF6101, HF6102; Baldwin PT539, PT-539; Fits Donaldson P557380, HFP557380, P779574, P779575; Fram C3954, C-3954; Wix 51533, 1350-6052; Fits Napa 1533; Purolator 6927810, H54552, PL4552H, PL-4552H; Luberfiner LH4912, LH8539, LH8542, LH-8542; AC Fits Delco PF2037, PF2038; Komatsu 175-60-27380, 07063-01100, 154-49-71990; Fits Caterpillar 8J8850, 8J-8850, 3I1358; Fleetrite HFR86101, HFR86102; Hastings HF-799; Parker 862F; Kralinator L-660; Sakura H5610, H-5610; Hifi SH56151; GMC 25012553

New aftermarket replacement part - not remanufactured, not used.
