A-C6290-20-20-W-AI (HW-C62) Code 62 Flange Head - 90� Elbow

One New Aftermarket Replacement (HW-C62) Code 62 Flange Head - 90-Degree Elbow Hydraulic Crimp Fitting

This W-Series Code 62 flange head 90-degree elbow (part number C6290-20-20-W) is a crimp-on hydraulic hose end fitting designed for high-pressure fluid power systems. It connects a dash-20 (1-1/4 in.) hose to a dash-20 (1-1/4 in.) Code 62 four-bolt flange port at a rigid 90-degree angle, providing a leak-free O-ring face seal. Skiving of the outer hose cover is required prior to crimping. Code 62 flanges conform to SAE J518 and are rated for high-pressure hydraulic circuits up to 6000 PSI, making them standard on mobile agricultural, construction, and industrial equipment.

Specifications

• Series: HW-C62 / W-Series (skiving required)
• Connection Type: Code 62 Four-Bolt Flange Head, 90-Degree Rigid Elbow
• Hose Size: Dash-20 (1-1/4 in. I.D.)
• Flange Port Size: Dash-20 (1-1/4 in.) Code 62
• Sealing: O-ring face seal
• Pressure Rating: SAE J518 Code 62 (6000 PSI series)
• Assembly: Crimp-on, skive required

Compatible Hose Types

Suitable for use with SAE 100R12, SAE 100R13, SAE 100R15, 4SH, and other high-pressure spiral and braided hydraulic hoses requiring skive-style fittings.

Replaces Part Number(s):

C6290-20-20-W

Aftermarket Interchange Numbers

BW-C62-20-20, C62-20-20W, C6290-20-20-W

New aftermarket replacement part - not remanufactured, not used.
