A-C6190-16-16-W-AI (HW-C61) Code 61 Flange Head - 90� Elbow
A-C6190-16-16-W-AI (HW-C61) Code 61 Flange Head - 90� Elbow
Couldn't load pickup availability
One New Aftermarket Replacement Code 61 Flange Head 90-Degree Elbow - Hydraulic Crimp Fitting
This SAE Code 61 flange head 90-degree rigid elbow is a W-style (bite-to-wire) hydraulic crimp fitting designed for use with 1-wire and 2-wire braided hydraulic hose. The rigid 90-degree bend routes high-pressure hydraulic lines in tight spaces, with the Code 61 split-flange head providing a secure, leak-free connection to Code 61 flange ports. Part of the A&I Products HW-C61 series of Code 61 crimp fittings.
Specifications
- Type: SAE Code 61 Flange Head - 90-Degree Rigid Elbow
- Style: W (Bite-to-Wire / Braided Hose)
- Hose Inside Diameter: 1 inch (-16)
- Flange Size: 1 inch (-16)
- Dim A: 1.000"
- Dim B: 5.190"
- Dim C: 3.080"
- Dim D: 1-5/16"
- Dim E: 2.800"
- Material: Steel
- Compatible hose types: 1-wire braided, 2-wire braided, R12 non-skive, 4SH non-skive, industrial hose
Compatible Applications
Universal hydraulic fitting - compatible with agricultural equipment, construction equipment, and industrial machinery using SAE Code 61 split-flange porting. Verify flange size and hose ID before ordering.
Replaces Part Number(s):
A-C6190-16-16-W-AI, C6190-16-16-W, 6190-16-16-W
New aftermarket replacement part - not remanufactured, not used.
