A-C61-16-16-W-AI (HW-C61) Code 61 Flange Head - Straight

One New Aftermarket Replacement (HW-C61) Code 61 Flange Head - Straight Crimp Fitting

This A-C61-16-16-W-AI is a straight, bite-to-wire crimp-on hydraulic hose end fitting featuring a SAE J518 Code 61 four-bolt flange head connection. It mates a 1" (dash-16) hose inside diameter to a 1" Code 61 SAE J518 flange port, providing a reliable O-ring face seal in hydraulic systems on agricultural equipment, construction machinery, and other fluid power applications. The W-Series bite-to-wire construction grips the steel reinforcement layer of the hose for superior holding strength compared to standard braided-hose crimp fittings.

Specifications

• Part Series: HW-C61 (W-Series Bite-to-Wire)
• Fitting Angle: Straight
• Flange Standard: SAE J518 / ISO 6162-1 Code 61
• Hose Inside Diameter (Side 1): 1" (Dash -16)
• Flange Size (Side 2): 1" Code 61 (Dash -16)
• Connection Type: Code 61 Four-Bolt Split Flange Head
• Material: Carbon Steel
• Seal Type: O-Ring Face Seal

Application Notes

Code 61 fittings are rated for standard-pressure hydraulic circuits. Do not interchange with Code 62 fittings - though visually similar, Code 61 and Code 62 have different bolt patterns and pressure ratings and will not form a safe or leak-free connection if mixed. Verify your port is a Code 61 (SAE J518 / ISO 6162-1) port before ordering. Compatible with SAE 100R1SN, SAE 100R2SN, SAE 100R16S, and SAE 100R17 hydraulic hose constructions.

Replaces Part Number(s):

A-C61-16-16-W-AI

Aftermarket Interchange Numbers

C61-16-16-W; interchanges with Kurt Hydraulics C61-W series

New aftermarket replacement part - not remanufactured, not used.
