A-321162R1-AI HD brake disc

Name: A-321162R1-AI HD brake disc
SKU: A-321162R1-AI
Price: 49.0 USD
Availability: InStock

A-321162R1-AI HD brake disc

£49.00 GBP

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

One New Aftermarket Replacement Heavy Duty Brake Disc Fits International Harvester (IH) and Fits Case IH Tractors, Combines, and Cotton Equipment

This heavy duty bonded brake disc is a direct replacement Fits International Harvester (IH) and Fits Case IH tractors, combines, cotton pickers, and cotton strippers. The disc installs in the brake assembly and provides consistent, reliable stopping power. Four discs are required per tractor (two per side) on most tractor applications; quantity per machine varies by model on combine and harvester applications -- verify quantity needed before ordering.

Specifications

Outer Diameter: 6.50"
Hub Diameter: 3.50"
Spline Count: 12
Thickness: 0.500"

Serial Number Restrictions

Fits International Harvester M and MV: Serial number 294226 and up (SN FBK294226 and up)
Fits International Harvester MD and MDV: Serial number 285505 and up (SN FDBK285505 and up)
Super M, Super MTA, Super MD, Super MDV, Super W6, Super WD6, 400, 450, W400, W450 series: all serial numbers with factory IH disc brakes

Compatible Models

Fits International Harvester / Fits FARMALL Tractors: M, MV, MD, MDV, Super M, Super MTA, Super MD, Super MDV, Super MV, Super WD6, Super WD6TA, Super W6, Super W6TA, W6, WD6, OS6, ODS6, 400, W400, 450, W450

Fits International Combines: 151, 151 Hillside, 181, 403, 503, 615, 616, 715, 815, 1420, 1440, 1460, 1620, 1640, 1644, 7440, 7445, 9900, 9910, 9920, 9930

Fits International Cotton Pickers / Harvesters: 141, 414, 416, 420, 422, 622, 782, 1400

Fits Case Combines: 800, 1010, 1060

Fits John Deere: AH19839, AH214069 cross-reference numbers suggest fitment on select Fits John Deere combine models -- verify application before ordering.

Replaces Part Number(s):

1963810C2, 1963810C1, 321162R1, 321162R91, 321162R92, 351117R91, 357112R1, 357112R91, 357112R92, 357117R91, 368179R91, 121961, 1219619C91, 121961C91, 121961C92, 38A60, 84466063, AH19839, AH214069

New aftermarket replacement part - not remanufactured, not used.

Models This Part Fits:

616, M, 450, 9930, Super WD6, 151, Super MD, 9910, MD, 181, 1460, 503, 615, W6, 1400, 9920, 400, 414, 815, W400, 403, 782, 151 Hillside, 95, 1440, 1640, 4420, WD6, 7440, 1420, MDV, 715, Super MTA, MV, 484, 7445, 422, Super W6, Super W-6, 4400, Super M, 416, 1644, 622, W450, 141, 9900, 420, 1620

Additional Information:

Diameter: 6.50" Hub: 3.50" Spline Count: 12 Thickness: .500"

Reference Numbers:

AH19839, AH214069, 121961, 1219619C91, 121961C91, 121961C92, 321162R1, 321162R91, 321162R92, 351117R91, 357112R91, 357117R91, 368179R91, 38A60, 1963810C1, 1963810C1, 357112R1, 357112R92, 84466063
