A-02307-AI 4.5- High Tensile Lacing

One New Aftermarket Replacement #4.5 High Tensile (RHTX) Clipper Belt Lacing - 12" Cards, Box of 12

This #4.5 High Tensile (HT) Clipper-style rectangular wire hook belt lacing is used to splice and repair conveyor belts, baler belts, pickup belts, and other agricultural and industrial belting. The rectangular high-tensile steel (RHTX) hook design delivers extra wire mass for enhanced splice life, superior strength, and superior wear resistance in abrasive and heavy-duty applications. Hooks are supplied carded (individual hooks secured to carding paper) on 12" strips for use with standard Clipper vise lacers and roller lacers. Compatible with belt thicknesses of approximately 3/16" to 7/32". Each box contains 12 cards of 12" lacing strips (no pins included).

Specifications

• Hook Series: #4.5 High Tensile (HT) - Rectangular Cross Section (RHTX)
• Card Length: 12"
• Cards per Box: 12
• Material: High tensile steel
• Belt Thickness Range: approx. 3/16" - 7/32"
• Pins: Not included

Typical Applications

Baler belts, combine pickup belts, conveyor belts, and other agricultural and industrial flat belting requiring a durable mechanical splice. Commonly specified for New Holland round baler belts and similar equipment.

Replaces Part Number(s):

A-02307-AI

New aftermarket replacement part - not remanufactured, not used.
