87109826 PRESIEVE CLOSZ SLAT 1 5

One New Aftermarket Replacement Pre-Sieve (Closz Slat) Fits Case IH and Fits New Holland Combines

This adjustable pre-sieve features long-finger Closz slat construction with 1-5/8" wire spacing and a spring-loaded indexed handle, allowing operators to optimize opening and airflow for specific crop and harvest conditions. The pre-sieve mounts above the upper chaffer in the combine's cleaning shoe system, pre-cleaning material before it reaches the main sieve to improve separation efficiency and grain sample quality. This part has been superseded by OEM part number 47705147 (with additional adjustment hardware per Parts Bulletin 2018-004); aftermarket replacements remain available for original-design machines.

Specifications

• Wire Spacing: 1-5/8" (22 mm) Closz Slat
• Width: 61.938" (approx. 62")
• Length: 29.878"
• Style: Adjustable, long-finger
• Weight: approx. 57 lbs

Compatible Models

Fits Case IH Combines: AFX8010, 7120, 7230, 7240, 7250, 7260, 8010, 8120, 8230, 8240, 8250, 9010, 9120, 9230, 9240, 9250, 9260

Fits New Holland Combines: CR920, CR940, CR960, CR970, CR980, CR6.80, CR6.90, CR6090, CR7.90, CR7090, CR8080, CR8090, CR8.90, CR9040, CR9060, CR9070, CR9080, CR9.90, CX8.80, CR9090 (Non-Elevation)

Replaces Part Number(s):

87109826, 84462833, 87105820, 84083981, 87042470, A-87109826-AI

New aftermarket replacement part - not remanufactured, not used.
