400-12468-JN J&N Electrical Products Alternator

400-12468-JN J&N Electrical Products Alternator

£252.00 GBP
£252.00 GBP
Sale Sold out
Shipping calculated at checkout.
One New Aftermarket J&N Electrical Products Alternator

Tech Info:
-LESTER: 8173-2, 8195-2, 8207-2, FAMILY: Fits Delco CS144, VOLT: 12, AMPS: 140, CONDITION: New, REGULATOR CLOCK: 2:00, ROTATION DIRECTION: Clockwise, MOUNT HOLE ID 1: M10x1.50, MOUNT HOLE 1 TYPE: Threaded, MOUNT HOLE 2 TYPE: Unthreaded, MOUNTING EAR THICKNESS: 0.701", MOUNTING EAR THICKNESS: 17.800mm, MOUNTING EAR 2 THICKNESS: 1.969", MOUNTING EAR 2 THICKNESS: 50mm, FAN LOCATION: External, REGULATOR LOCATION: Internal, TERMINAL ID 2: B+, TERMINAL 2 SIZE: M8x1.25, TERMINAL ID 3: STA, TERMINAL 3 SIZE: Spade, TERMINAL ID 4: L, TERMINAL 4 SIZE: Spade, TERMINAL ID 5: IG, TERMINAL 5 SIZE: Spade, TERMINAL ID 6: S, TERMINAL 6 SIZE: Spade, POLARITY: Negative, NUMBER OF GROOVES: 6, GROOVE OD: 2.185", GROOVE OD: 55.500mm, PULLEY TYPE: Solid, PULLEY OUTER DIAMETER: 2.362", PULLEY OUTER DIAMETER: 60mm, WARRANTY: 1 Year, : (2) M10-1.5 Threaded Mounting Bosses in Rear of SRE Frame
-AC Fits Delco Tools: 321-1059, 321-1110, 321-1112, 334-2436; Arrowhead: ADR0237; Fits Bosch: AL8575X; Fits Delco: 10463534, 10463677, 10463679, 10480139, 10480200, 10480202, 321-1110, 321-1112, 334-2436; J&N Electrical Products: 400-12468; Lester: 8173-2, 8195-2, 8207-2; Fits Lucas Electric: LRA01809

Replaces Part Number(s): 400-12468

Additional Information:

LESTER: 8173-2, 8195-2, 8207-2, FAMILY: Delco CS144, VOLT: 12, AMPS: 140, CONDITION: New, REGULATOR CLOCK: 2:00, ROTATION DIRECTION: Clockwise, MOUNT HOLE ID 1: M10x1.50, MOUNT HOLE 1 TYPE: Threaded, MOUNT HOLE 2 TYPE: Unthreaded, MOUNTING EAR THICKNESS: 0.701", MOUNTING EAR THICKNESS: 17.800mm, MOUNTING EAR 2 THICKNESS: 1.969", MOUNTING EAR 2 THICKNESS: 50mm, FAN LOCATION: External, REGULATOR LOCATION: Internal, TERMINAL ID 2: B+, TERMINAL 2 SIZE: M8x1.25, TERMINAL ID 3: STA, TERMINAL 3 SIZE: Spade, TERMINAL ID 4: L, TERMINAL 4 SIZE: Spade, TERMINAL ID 5: IG, TERMINAL 5 SIZE: Spade, TERMINAL ID 6: S, TERMINAL 6 SIZE: Spade, POLARITY: Negative, NUMBER OF GROOVES: 6, GROOVE OD: 2.185", GROOVE OD: 55.500mm, PULLEY TYPE: Solid, PULLEY OUTER DIAMETER: 2.362", PULLEY OUTER DIAMETER: 60mm, WARRANTY: 1 Year, : (2) M10-1.5 Threaded Mounting Bosses in Rear of SRE Frame, AC Delco Tools: 321-1059, 321-1110, 321-1112, 334-2436; Arrowhead: ADR0237; Bosch: AL8575X; Delco: 10463534, 10463677, 10463679

Reference Numbers:

400-12468
