201-24001-JN J&N Electrical Products Pulley

201-24001-JN J&N Electrical Products Pulley

£19.00 GBP
£19.00 GBP
Sale Sold out
Shipping calculated at checkout.
One New Aftermarket J&N Electrical Products Pulley

Tech Info:
-Arrowhead: ABO5001; Fits Bosch: 1-126-600-154, 1-126-600-222, 1-126-600-262, 1-126-600-265, 1-126-600-308, 1-126-600-309, 1-126-600-345, 1126600348, 1-126-600-348, 1126600488, 1-126-600-488, 1-126-600-544; J&N Electrical Products: 201-24001; Other OEMS: B9028-018
-BELT WIDTH: 10, CENTER OF GROOVE TO REAR: 1.339", CENTER OF GROOVE TO REAR: 34mm, GROOVE TYPE: V-Groove, ID: 0.669", ID: 17 mm, KEYWAY WIDTH: 0.197", KEYWAY WIDTH: 5mm, NUMBER OF GROOVES: 1, NUT RECESS: 1.398", NUT RECESS: 35.500mm, OD: 2.874", OD: 73 mm, PULLEY TYPE: Solid, THICKNESS: 43 mm

Replaces Part Number(s): 201-24001

Additional Information:

Arrowhead: ABO5001; Bosch: 1-126-600-154, 1-126-600-222, 1-126-600-262, 1-126-600-265, 1-126-600-308, 1-126-600-309, 1-126-600-345, 1126600348, 1-126-600-348, 1126600488, 1-126-600-488, 1-126-600-544; J&N Electrical Products: 201-24001; Other OEMS: B9028-018, BELT WIDTH: 10, CENTER OF GROOVE TO REAR: 1.339", CENTER OF GROOVE TO REAR: 34mm, GROOVE TYPE: V-Groove, ID: 0.669", ID: 17 mm, KEYWAY WIDTH: 0.197", KEYWAY WIDTH: 5mm, NUMBER OF GROOVES: 1, NUT RECESS: 1.398", NUT RECESS: 35.500mm, OD: 2.874", OD: 73 mm, PULLEY TYPE: Solid, THICKNESS: 43 mm

Reference Numbers:

201-24001
