1U0593 Edge-Cutting Fits Caterpillar Models

One New Aftermarket Replacement Loader Bucket Cutting Edge for Caterpillar (Cat) Wheel Loaders

This aftermarket replacement cutting edge (part number 1U0593) is a bolt-on center cutting edge designed for the bucket of Caterpillar (Cat) wheel loaders. It features a double-bevel, reversible design made from alloy steel, allowing the edge to be flipped for extended service life. Weighing approximately 195 lbs (88 kg), this heavy-duty ground engaging tool protects and replaces worn bucket edges on 960- through 980-series Cat loaders.

Specifications

• Blade Type: Double Bevel, Reversible
• Length: 51.875 in (1319 mm)
• Width: 14.17 in (360 mm)
• Thickness: 1.1875 in (30 mm)
• Bolt Diameter: 1.25 in
• Number of Bolt Holes: 3
• Hole 1 Distance (end to center): 8.310 in
• Hole Spacing (center to center): 16.875 in
• Hardware Required: 3x 1-1/4 in x 4-1/2 in plow bolts, 3x 1-1/4 in hex nuts (not included)
• Weight: 195 lbs (88 kg)
• Mount: Bolt-on center

Compatible Models

Caterpillar Wheel Loaders: 924G, 924K, 930K, 938K, 950F II, 950G, 950G II, 950H, 950K, 960F, 962G, 962G II, 962H, 962K, 963C, 963D, 966D, 966F, 966F II, 966G, 966G II, 966H, 966K, 970F, 972G, 972G II, 972H, 972K, 980H

Replaces Part Number(s):

1U0593, 1U-0593

New aftermarket replacement part - not remanufactured, not used.
