One New Aftermarket Replacement Cutting Edge End Bit for Komatsu D-Series Crawler Dozers
This bolt-on cutting edge end bit mounts to the outer corners of the dozer blade, protecting the blade ends from wear during grading, pushing, and excavation work. It is a level cut design that fits both the right-hand and left-hand positions on the blade. Bolts and nuts are sold separately.
Specifications
- Thickness: 5/8 in. (16 mm)
- Width: 6.3125 in. (160 mm)
- Length: 14.1875 in. (380 mm)
- Bolt holes: 4 holes, 5/8 in. bolt diameter
- Bolt hole spacing: 3.125 in. center to center
- Hardware required: (4) 5/8 in. x 2 in. plow bolts and (4) 5/8 in. hex nuts (sold separately)
- Style: Level cut, right-hand or left-hand
Compatible Models
Komatsu D31 Series: D31A-17, D31A-18, D31A-20, D31E-17, D31E-18, D31E-20, D31P-17, D31P-18, D31P-20, D31EX-21, D31EX-21A, D31PX-21, D31Q-17, D31Q-18, D31Q-20
Komatsu D37 Series: D37EX-21A, D37PX-21
Komatsu D39 Series: D39EX-21
Komatsu D41 Series: D41E, D41P
Replaces Part Number(s):
11G-71-31170, 11G7131170
New aftermarket replacement part - not remanufactured, not used.
